4 Inch 0.5HP 0.75HP 1HP 1.5HP 2HP 3HP 4HP 5.5HP 7.5HP 10HP AC Three Phase Oil Cooled Submersible Motor

Availability:
  • 4 Inch Three Phase Motor

  • Liyuan ATA

Product Description

4 Inch 0.5HP 0.75HP 1HP 1.5HP 2HP 3HP 4HP 5.5HP 7.5HP 10HP AC Three Phase Oil Cooled Submersible Motor



DescriptionSubmersible Motor
SpecificationAC Motor
Motor Size4 Inch
Power0.37kw 0.55kw 0.75kw 1.1kw 1.5kw 2.2kw 3kw 4kw 5.5kw 7.5kw
0.5hp   0.75hp  1hp     1.5hp     2hp    3hp   4hp  5.5hp   7.5hp   10hp
VolotageSingle Phase :110V, 220V,
Three Phase :380V, 410V,440V,480V

According to the customer customized voltage
MaterialStainless steel
Motor Top Cover Cast Iron   /   Stainless Steel   /  Copper
MediumClear water,
Hot water

Acceptance customized for acid and alkaline water
ControllerAC Inverter :MPPT
AC Multi-function all-in-one Inverter
DC Controller
AC/DC Controller
PowerElectric,   Solar
BrandLiyuan ,ATA, Accept custom brand









 Three Phase

Motor PowerCurrentPower FactorLength Weight
HPKWAcosmmkg
0.50.371.20.683717.5
0.750.551.60.683908.4
10.751.80.704108.9
1.51.13.10.724209.7
21.54.00.7444511.2
32.25.60.7657813.8
437.60.7764918.2
5.549.60.7971421.5
7.55.514.00.881426.5
107.516.50.894932.4
